| Printhead |
Two on-demand piezo heads
|
| Print resolution |
1,200dpi max
|
| Maximum Print Width |
25.2” (640mm)
|
| Maximum media width |
25.6” (650mm)
|
| Maximum Media Diameter |
9.84” (250mm) or less
|
| Maximum Media Weight |
99 lbs (45 kg) or less
|
| Ink Type |
4C+4SP (CMYK+WWClCl)
UV curable flexible ink ELS-170 CMYK
UV curable hard ink ELH-100 White/Clear
|
| Interface |
Ethernet 1000 BASE-T / USB2.0 Hi-speed
|
| Power Supply |
AC100～120/200～240V±10％, 50/60Hz±1Hz×1
|
| Power Consumption |
100V – 1,440W or less, 200V – 1,920W or less
|
| Operational Environment |
Temperature: 68-86 F (20° – 30°C)
Humidity: 35 – 65 % RH (Non condensing)
|
| Dimensions (W × D × H) |
82” x 37” x 58” (2,090 × 930 × 1,475 mm)
|
| Weight |
367 lbs (180kg)
|
| Certifications |
VCCI class A、FCC class A、IEC62368-1 ETL, CE Marking (EMC Directive, Low Voltage Directive, RoHS), CB report, ENERGY STAR, RCM, KC
|
| *Specifications subject to change. |
|
